SOT-223-5 Voltage Regulator Evaluation Board User’s Guide
2.3
GETTING STARTED
The SOT-223-5 Voltage Regulator Evaluation Board is fully assembled and tested. All
that is required for operating is a user supplied voltage regulator and a supply voltage
source. Some of the tests that may be completed using the SOT-223-5 Voltage
Regulator Evaluation Board shall now be described.
2.3.1
Ground Current and Quiescent Current
When measuring ground current, jumper JP3 should be removed, otherwise leave
jumper JP3 on. To meaure ground current, perform the following steps.
1. Add desired load resistors to R 5 and R 6 .
2. Remove jumpers JP3, JP4, and JP5.
3. Connect an Ampere Meter across test points TP6(+) and TP7(-). Select the
appropriate meter scale for the device being evaluated.
4. Connect a voltmeter across testpoints TP9(+) and TP10(-).
5. Add jumper JP1.
6. Add jumper JP2 to pins 1 and 2.
7. Apply source voltage to test points TP1(+) and TP2(-).
8. Verify the voltage across test points TP6 and TP7 is within the expected range of
the device being tested.
9. Read the Ground Current directly from the ampere meter connected to test
points TP6 and TP7.
10. Vary the input voltage to obtain data for ground current versus input voltage.
With no load attached to the output of the voltage regulator, the measured
ground current is also called the quiescent current of the regulator.
11. Add a load selection jumper, JP4 or JP5.
12. Read the Ground Current directly from the ampere meter connected to test
points TP6 and TP7.
13. The data collected will be the ground curren t versus load current.
2.3.2
Adjustable Output Voltage
The output voltage of some adjustable voltage regulators may be adjusted by selecting
appropriate resistor divider values connected to the Adjust (ADJ) pin. R 2 and R 3 pads
are available to be used as voltage divider.
2.3.3
Shutdown Input Selection
The Shutdown (SHDN) input selection may be set to V IN , GND, or a user supplied
voltage using test point TP5. To select V IN as the SHDN voltage, place a jumper across
pins JP2-1 and JP2-2. To select GND as the SHDN voltage, place a jumper across pins
JP2 and JP3. To select a user specified input such as a function generator, remove the
jumper from JP2 and connect the external voltage source positive lead (+) to test point
TP5 and the negative lead (-) to test point TP4.
DS51751A-page 8
? 2008 Microchip Technology Inc.
